    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine

    Ask Lasest Price
    Brand Name : YuTeng Machinery
    Certification : CE
    Payment Terms : T/T
    Model Number : YGH Series
    • Product Details
    • Company Profile

    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine

    Ultra High-Speed Computer Shuttle Multi-Needle Quilting Machine

    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine

    Product Description:

    It is widely used for quilting high-quality garments, quilt covers,hand bags,gloves,sleeping bags,pajamas,bedspreads,seat covers,plus material and household ornaments.


    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting MachineComputerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine

    Special Features:

    1.Comprehensively upgrade and strengthen each transmission structure to truly realize high-speed operation and stable production.

    2. The computer can adjust the speed of 100-1400 rpm, and the stitch adjustment is 2-12mm.

    3. The speed, stitch and various pattern compensation functions can be adjusted arbitrarily during the operation of the equipment.

    4. The system is equipped with a "return” function to solve the work of missing quilting and stitching between processing and changing shuttles.

    5. The needle row movement adopts servo drive mode, and the spindle adopts frequency conversion control.

    6. Dual clutch device, to solve the synchronization problem of rollers in front and back.

    7. 360 degree free quilting come with unlimited multi-span quilting independent patterns.

    8. Automatic thread-break detection unit. Infrared sensor make sure more safety operation.

    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting MachineComputerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting MachineComputerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting MachineComputerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting MachineComputerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting MachineComputerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine


    Machine Specification:

    Model80 Series
    80-2-3(S/B)80-3-4/4.5/5/6(S/B)
    Dimension(L*W*H)3900mm*1400mm*1800mm3900mm*1400mm*1800mm
    Quilting Width2000mm2000mm
    Needle rows23
    Space between needle rows3"3"+1"/1.5"/2"/3"
    Space between needle25mm25mm
    X-axis movement displacement152.4mm(6")152.4mm(6")
    Thickness of quilting≤25mm≤25mm

    *Customized model are available to meet client’s various needs

    Company Certificate:

    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine

    Support and Services:

    1. All parts are guaranteed one year for non-human-made damage
    2. Before buying, our businessman online 12 hours every working day to answer your questions
    3. In production,production pictures and videos are available any time
    4. After buying,our engineer online 10 hours every working day to help you use machine correctly
    5. We provide details machine installation & user’s guide and maintenance manual

    Packing and Shipping:

    To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging

    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine

    Computerized High-Speed Factory Shuttle Lock Stitch Multi Needle Quilting Machine

    FAQ:

    Q1: Warranty,Quality and Service
    A:We provide one year warranty,within one year,If machine damaged,we provide parts free;And we provide online guidance within 12 hours,lifetime service

    Q2: Experience,Professional and Engineer
    A:We are a quilting machine manufacturer with 10 years experience,Our engineer online eight hours every day,we will give best guide before buying and after buying

    Q3: Advantage and Why choose us
    A:We have are rich experience, professional team, never absent after-sales service we helped many many customers in the world,we are growing up together with all of our customers


    *Welcome to contact with us,for more information of quilting machine.
